VesselTRack

Key Features

• Dual-channel AIS receiver for reliable maritime vessel tracking
• Receives and decodes AIS Class A and Class B transponders
• Supports AIS SARTs and Aids to Navigation for broader maritime awareness
• 19-inch 2U rack-mount enclosure for integration into existing systems
• Wide-range power supply supporting 9–72 VDC or 115–230 VAC
• Full Ethernet connectivity for network-based data communication
• Multiple data output formats for flexible system integration
• Open software architecture for customised solutions
• Plug-and-play system kit supplied with high-sensitivity AIS, ADS-B and GPS antennas
• Unified data formats for integration with PlaneTRack, DroneTRack and other surveillance systems
• Optional Cambridge Pixel display software for vessel surveillance visualisation
• Extended-temperature configuration available for demanding operating environments

Key Specifications

• Receiver: AIS
• Receiver Type: Dual-channel AIS receiver
• Rack Width: 19-inch
• Rack Height: 2U
• RF Input: 2 × N(f), 50 Ω
• AIS Reception: AIS Class A, Class B, AIS SART and Aids to Navigation
• Network Interface: Ethernet
• Data Protocols: UDP, TCP, HTTP, NTP
• Data Formats: NMEA/IEC, JSON, CSV and other standardised output formats
• Power Supply: 9–72 VDC or 115–230 VAC
• Operating Temperature: Standard -10°C to +50°C; extended-temperature option available from -30°C to +70°C
• Enclosure: 19-inch 2U rack mount
• Cooling: Natural convection
• Software: Open software architecture; optional Cambridge Pixel display software
• Applications: Industrial and offshore surveillance, critical infrastructure monitoring, maritime surveillance and mobile or stationary defence systems
